About CHETAN METALS
Our Expertise in Casting and Machining
At CHETAN METALS, we specialize in high-quality casting and machining services tailored for manufacturing industries. Our team is committed to delivering precise metal components that meet strict quality standards and deadlines. We leverage advanced technology and craftsmanship to ensure durability and performance in every product we produce.
GRADES MANUFACTURED
GRADES OF STEEL & ALLOY STEEL MANUFACTRED AS PER STANDARDS
IS STANDARDS
Carbon Steel : IS–2708, IS–2707, CS–700
Low Alloy Steel : LW–106 21, M 201–GrE, API–6A–60 K, WCB, WCC
BS STANDARDS
Carbon Steel : EN–1.0621, EN–1.0619, EN-1.0625
Low Alloy Steel : EN–1.1131, EN–1.6220
Stainless Steel : EN–1.4309, EN–1.4408, EN–1.4552, EN–1.4409, EN–1.4581
ASTM STANDARDS
Carbon Steel : WCB, WCC
Low Alloy Steel : LCC, LCB,WC6,LC1,WC9
Stainless Steel : CF–8, CF–8M, CF–3, CF–3M, CF–8C, 4A, 5A, 6A, CA–15, CA–40
CERTIFICATIONS
PRODUCTION FACILITY
Melting Furnace : FLUXO MAKE 300 kg – 1NO, 500 kg – 1NO & 1000 kg – 1NO.
Temperature Measuring : Liquid metal temperature checking digital pyrometer Machine.
Connected Power Generator : 375 KVA, 20 KVA DG set
Moulding Machines
• Omega Sane make continuous mixer rated 10 MTPH with reclamation plant with ALFA set no bake sand molding system.
• Muller- 2Nos. specifications.
• Alfa set No bake Process
• CO2 sand Process
• Shell Process
TESTING FACILITY
SPECTROMETER : METAL POWER 1008i Model suitable for all steel and alloy steel grades can check 24 elements with nitrogen tracing.
CA/Si Analyzer : Latest model with new feature which measures bath temperature. Prediction of BHN/RM & has facility to record and print.
Microscope : Latest model with image analyze system
Hardness : FIE Make Hardness Testing Machine.
PATTERN FACILITY
Complete facilities for New pattern development, pattern Mounting, Repairing and storage
FINISHING FACILITY
•Table top double door Inda Bratar make 500 Kg, 48” dia table.
• Hanger type : 2 MT capacity & 500 Kg capacity.
•Table grinding machines – 2 nos.
• Swing frame machines
• Flexible shaft grinders
• Welding and gauging Machines
HEAT TREATMENT & QUENCHING
Electrical furnace with automatic heating recorder and graph . 2 ton capacity size 1.5M X 1.5M X 2M HT casting that meets your specific requirements.
MACHINING FACILITY
Lathe : HMT, PSG, Kirloskar, Investa & Batala– Total 12 no.
Milling machine : HMT Make FN2, FN3 – vertical and horizontal – Total 3 Nos
Shaping Machine : 24’’ Stroke Length
Dynamic Balancing Machine : 30 Kgs and 16’’ Dia
Measuring Instruments : Vernier caliper up to 1 mtr length, Depth Micrometer up to 150 mm, Inside Micrometer 0-1000 mm, Inside Micrometer 0-1000 mm, Bore dial gauge 0-300 mm, Height gauge – 300 mm
Complete Pneumatic / Hydraulic test bed for Valves.
